The Franco Garda

We have created the most
versatile stretcher on the market.

Designed by French and Italian mountain rescue specialists, the FRANCO GARDA rescue stretcher is a high-performance, versatile, reliable and easy-to-use tool. It allows rescue interventions on any type of terrain: high mountains, walls, sea, canyon as well as on snow.
It is made up of a light and resistant structure, a patented joint concept and a high-performance medical system.
Its design allows quick adaptation of specific accessories: carrying arm, wheel, float, anti-rotation drift, ski guidance.

The FRANCO GARDA provides maximum performance to contribute to the success of the rescue.



The Franco Garda stretcher must be returned every 10 years for a complete check.



Any modification made to the product without prior approval from TSL Rescue, the supplier, is strictly prohibited, resulting in the forfeiture of the 10-year warranty.

  • la_chamoniarde
  • JEC
  • alcotra
Séquence 10.00_00_00_00.Still001

Standard equipement

  • Medical cover
  • Standard sling
  • 4 external attachment straps
  • Carrying harness
  • Wheel
  • Carrying bars
PHOTOS_DARIO_094 (752)

The Franco Garda stretcher can be used in an aquatic environment.
It is approved for rescue on most helicopters.

In order to meet the requirements of solidity and safety, the Franco Garda stretcher is composed of a tubular frame in ions covered with solid and repairable composite material.

The patented hinge system allows the stretcher to be folded, separated into three elements and to ensure double locking when fitting the carabiner.

Groupe de masques 46

The shell, (tubular structure in stainless steel covered with twintex), is light and extremely resistant. The articulation/separation system allowing the choice to fold up or separate the three parts of the shell, has no loose parts and is easy to handle, even in extreme conditions.

IMG_0248-9

The medical cover is equipped with a high-performance device for immobilizing the patient, as well as quick access pockets for the upper and lower limbs of the injured person. The stretcher comes with the medicalization cover and the set of slings for winching.

IMG_0526-34

The medicalization system has been studied in collaboration with French and Italian doctors specialized in mountain rescue. The patient immobilization device is effective and complete: padded flaps for thoracic support, comfort mattress in closed cells, adjustable head support, reinforced straps, immobilization of the feet.

IMG_0792

Features techniques

Reference Weight Dimensions Dimensions once folded Resistances
PFFG001 13,4 kg 185 x 54 cm 105 x 54 x 26 cm 1 200 kg
PFFG002 13,4 kg 200 x 54 cm 105 x 54 x 26 cm 1 200 kg
Groupe de masques 44
The stretcher Franco Garda can be used in an aquatic environment
Groupe de masques 43
It is approved for rescue
on most helicopters.
DSCN0886

découvrez nos accessoires

MATELAS ATTACHE

Vacuum Mattress with transport backpack and vaccum pump.

MATELAS DETACHE

Vaccum mattress.

Sac Transport Matelas Depression

The transport backpack of the vaccum mattress.

binary comment

Standard carrying bars L150

binary comment

Handle for carrying bar

binary comment

Carrying harness

derive ouverte

Anti-rotation rudder
